Armored 6 core fiber optic cable multicore GYXTC8Y with
aramid inside 1.50mm solid steel messenger
* "R" means Ring Mark.
Cable structure and parameter
* The nominal sheath thickness may vary by ±0.2mm.
** The nominal outer diameter and height may vary by ±0.4mm.
Zhuhai Surelink Communication Cable Co.,Ltd is one of the leading manufacturer in the cables
and telecom accessories. We have more than 20 years experience in this line.Our factory has over
twenty production lines and 300 employees.
Our productions comply with ISO9001.Professional team,powerful factory and strict quality control give
best service to our clients and the quality guarantee in every order.
Our products have been widely installed in Telecom companies and many distributors around the world.
We export to more than 70 countries and our annual revenue is more than hundreds of million USD.
We have established a close relationship with many companies around the world and we sincerely look
forward to woking with all clients from all over the world.
OEM and ODM order highly welcome !
Payment
We usually use T/T
T/T deposit before production and balance when shipment.
Payment terms: Western Union, Escrow, Paypal, T/T ,L/C
Shipping
If the quantity of the order is not very big, we usually send by express delivery,such as TNT,DHL,UPS,
FEDEX or EMS.
For big order,we will ship the goods by air or by sea.
aramid inside 1.50mm solid steel messenger
Cable Structure |
Technical Parameters |
Fiber color code
No | 1 | 2 | 3 | 4 | 5 | 6 |
Color | Blue | Orange | Green | Brown | Slate | White |
No | 7 | 8 | 9 | 10 | 11 | 12 |
Color | Red | Black | Yellow | Violet | Pink | Aqua |
No | 13 | 14 | 15 | 16 | 17 | 18 |
Color | Blue+R | Orange+R | Green+R | Brown+R | Slate+R | White+R |
No | 19 | 20 | 21 | 22 | 23 | 24 |
Color | Red+R | Natural+R | Yellow+R | Violet+R | Pink+R | Aqua+R |
* "R" means Ring Mark.
Cable structure and parameter
Fiber number | Tube Diameter | Messenger steel wire diameter | Sheath thickness (nominal*) | Diameter W*H (Nominal*) | Weight (Approx.) |
mm | mm | mm | mm | kg/km | |
2~12 | 3 | 1.6mm | 1 | 5.0×10.1 | 45 |
14~24 | 3.6 | 1.6mm | 1 | 5.6×10.7 | 50 |
** The nominal outer diameter and height may vary by ±0.4mm.
Optical Characteristics: | ||||
Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber |
A1b:62.5/125 | ||||
Singlemode | G.652(A,B,C) | B1.1:Conventional fiber | ||
G.652D | B2: Zero dispersion shifted | |||
G.655 | B1.2 :Cut-off wavelength shifted | |||
G.657(A1,A2 ,B3) | B4: Main technical data for positive dispersion shifted single-mode fiber |
Related Package |
Package Details:
Iron-wooden drum or fumugated wooden drum,normal wooden drum
Drum size can be designed,details will calculation for suitable for containers
